| Optical Geometry |
D/8 (diffused illumination, 8-degree viewing angle), SCI & SCE (spcular component included/specular component excluded) Mode |
| Meet The Criteria |
CIE No. 15, GB/T 3978, GB 2893, GB/T 18833, ISO 7724-1, ASTM E1164, DIN 5033, Teil 7 |
| Integrating Sphere Size |
Φ40mm |
| Light Source |
Combined Full Spectrum LED light source |
| Spectrophotometric Mode |
Nano-integrated Spectral Device |
| Sensor |
Large-area silicon photodiode array (double-row 18 group) |
| Wavelength Range |
400~700nm |
| Wavelength Interval |
10nm |
| Reflectance Range |
0~200% |
| Measuring Apertures |
Six Apertures: 3mm Flat + 3mm Conical; 5mm Flat + 5mm Conical; 10mm Flat + 10mm Conical |
| Locating Method |
Stabiliser position+camera locating |
| Whiteboard Calibration |
Non-contact automatic calibration |
| SCI/SCE |
SCI+SCE |
| Color Spaces |
CIE LAB, XYZ, Yxy, LCh, CIE LUV, s-RGB, HunterLab, βxy, DIN Lab99 Munsell(C/2) |
| Color Difference Formula |
ΔE*ab, ΔE*uv, ΔE*94, ΔE*cmc(2:1), ΔE*cmc(1:1), ΔE*00, DINΔE99, ΔE(Hunter) |
| Other Colorimetric Index |
Spectrum Reflectance Rate, WI (ASTM E313, CIE/ISO, AATCC, Hunter, Taube, Berger, Stensby), YI (ASTM D1925, ASTM 313), Metamerism Index MI, Staining Fastness, Colour Change Fastness, Strength, Hiding power, 555 hue classification, Munsell (C/2), Blackness (My,dM), Colour Density CMYK, Tint (Some functions require PC software implementation) |
| Observer Angle |
2°/10° |
| Illuminants |
D65, A, B, C, D50, D55, D75, F1, F2 (CWF), F3, F4, F5, F6, F7(DLF), F8, F9, F10 (TPL5), F11 (TL84), F12 (TL83/U30), U35, NBF, ID50, ID65, LED-B1, LED-B2, LED-B3, LED-B4, LED-B5, LED-BH1, LED-RGB1, LED-V1, LED-V2 (Partial functions require PC software implementation) |
| Displayed Data |
Spectral Graph/Data, Sample Chromaticity Values, Colour Difference Value/Graph, PASS/FAIL Result, Colour Simulation, Colour Deviation |
| Measuring Time |
About 1s |
| Repeatability |
Chromaticity Values: MAV/SCI, within ΔE*ab 0.025 (after warm-up and calibration, based on the average of 30 white tile measurements at 5—second intervals) Spectral reflectance: MAV/SCI, standard deviation within 0.07% (400~700nm) |
| Inter-instrument Error |
Inter-Instrument agreement. MAV/SCI, ΔE*ab ≤ 0.3 (average of measurements from 12 BCRA Series Ⅱ colour tiles） |
| Displayed Accuracy |
0.01 |
| Measurement Mode |
Single measurement, average measurement (2~99 times) |
| Reflectance Resolution |
0.01% |
| Size |
120mm X 75mm X 207mm |
| Weight |
367g (calibration base excluded) |
| Battery |
Lithium battery, 3.7V, 5000mAh, 8000 cycles in 8 hours |
| Illuminant Life Span |
More than 1.2 million measurements over 10 years |
| Display |
3.5 inch TFT true colour, Capacitive Touch Screen |
| Data Port |
USB, Bluetooth |
| Data Storage |
500 pcs standard samples, 15,000 pcs samples (one piece of data can include SCI+SCE at the same time), PC mass storage |
| Software Support |
Android, IOS, Windows, Wechat small program, Hongmeng |
| Language |
Simplified Chinese, Traditional Chinese, English,Russian |
| Operating Environment |
0~40℃, 0~85%RH (no condensing), Altitude < 2000m |
| Storage Environment |
-20~50℃, 0~85%RH (no condensing） |
| Accuracy Assurance |
Guaranteed to meet Class 1 measurement standards. |
| Standard Accessories |
Power adaptor, data cable, user manual, quality management software (download from official website), calibration box, protective cover, wrist strap, measurement apertures. |
| Optional Accessories |
Micro-printer, Powder Test Box. |
