TQC Sheen Paint Impact Tester
Manufactured by TQC Sheen
Relied upon across coating laboratories worldwide, the TQC Sheen impact tester for paint will help you to finesse your paint production, surface finishing, and powder coating applications.
This dual scale impact tester is precision engineered and has an inbuilt spirit level for high accuracy to give you complete confidence when assessing the durability and resilience of powder coatings.
Price on quotation
Benefits
- Quickly and accurately determine the impact resistivity and flexibility of most coatings.
- Equipped with a special guidance, assuring that the distance between each impact is always according to the standard.
- Ideal for coating laboratories, paint production, surface finishing, and powder coating.
- Helps manufacturers and quality control teams ensure that the paint coating meets performance standards and maintains its protective integrity in demanding environments.
- Each paint impact test comes as a complete set (instrument and accessories) to perform a test according to DIN/ISO 6272, ASTM D2794, and ASTM G14.
- Wide range of impact test models available for performing direct and/or indirect impact tests (See Models & Accessories for full details).
Suitable Applications & Materials
Applications: Coating testing, flexibility testing, hardness testing.
Materials: Aluminium, inks and coatings, metals, steel.
SP1880: Impact test according to ISO 6272-2 / ASTM D2794
Impact tester with which indirect impact tests can be performed according to ISO 6272-2 / ASTM D2794
Content: base plate assembly, guide tube, release collar, punch Ø12,7 mm , punch Ø15,9 mm, weight 1 kg, die Ø16,3 mm. Max test panel thickness: 4,5 mm
SP1890: Impact test according to ISO 6272-1
Impact tester with which direct impact tests can be performed according to ISO 6272-1
Content: base plate assembly, guide tube, release collar, clamp device, ball Ø20 mm, die 27mm, weight 1000 gr Max. test panel thickness: 1,25mm
SP1891: Impact test according to ISO 6272-1 / ASTM D2794 (before 1993)
Impact test with which direct impact tests can be performed acc. to ISO 6272-1 and ASTM D2794 (before 1993).
Content: base plate assembly, guide tube, release collar, clamp device, ball Ø20 mm, die 27mm, weight 1000 gr, ball Ø15,9 mm, die 16,3mm, weight 900g
SP1895: Impact test according to ASTM G14
Impact test with which direct impact test can be performed according to ASTM G14
Content: base plate assembly, guide tube, release collar, clamp device, punch Ø15.9 mm, weight 1.361kg and a V-notch vise with spring clamp to hold the pipe
SP1896: Impact Test according to CSA
Standards for impact testing
| SP1880 | SP1890 | SP1891 | SP1895 | SP1896 | |
| Type of Impact | Indirect | Direct | Direct | Direct | Direct |
| ISO 6272-2:2002 | • | ||||
| ISO 6272-2:2002 | • | ||||
| ISO 6272:1993 | • | ||||
| ASTM D 2794:2004 | • | ||||
| ASTM G14-04 | • | ||||
| JIS K 5600-5-3:1989 | • | • | |||
| EN 12206-1:2004 | • | • | • | ||
| EN 13523-5:2001 | • | • | |||
| AAMA 2605-05 | • | • | |||
| Qualicoat 2006 | • | • | |||
| Qualisteelcoat 2008 | • | • | |||
| Canadian Standards Association (CSA) | • |
