Rapid Dynamic Climate Chambers, Extended Range Series MKT

Rapid Dynamic Climate Chambers, Extended Range Series MKT

Manufactured by BINDER

The MKT Series Dynamic Climate Chamber is designed for use in science, research, laboratories and industrial applications. It has an extended temperature range of -70°C to 180°C, along with the added benefit of natural simulation.

This BINDER climate chamber fills the very highest precision and performance requirements for cyclical temperature tests, and is available in three different sizes (115 litres, 228 litres, or 734 litres interior volumes).

All standard models come with a voltage of 400V, while the MKT with voltage and frequency converter has a voltage of 480V.

Benefits

  • Comprehensive programming and data acquisition.
  • APT.line™ preheating chamber technology ensures homogeneous climate conditions.
  • Temperature range of -70°C to +180 °C.
  • Programmable condensation protection for test material.
  • Heated viewing window with LED interior lighting so you can easily see what’s going on inside the chamber.
  • BINDER Multi Management software APT-COM™ Basic Edition.
  • Troubleshooting system with visual and audible alarms.
  • Intuitive touchscreen controller with time-segment and real-time programming.
  • Internal data logger, measured values can be read out in open format via USB.
  • Access port with silicone plug: 50 mm, left.
  • Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm.
  • 4 castors, two with brakes for easy manoeuvrability of the chamber from A to B.
  • Computer interface: Ethernet.
  • Adjustable ramp function.
  • Integrated chart recorder.
  • Real-time clock.
  • Door heating.
  • Stainless steel rack.
  • Inner chamber made of hygienic and robust stainless steel.
  • CFC-free refrigerants R-452A and R-23.
  • Cooling with cascade compressor cooling unit.
Model Interior Volume (L) Temperature Range Internal Dimensions (mm) Housing Dimensions (mm) (Not including fittings and connections)
MKT115-400V 115 -70°C to +180 °C 600 (W) x 480 (H) x 400 (D) 720 (W) x 1445 (H) x 780 (D)
MKT115-480V-C 115 -70°C to +180 °C 600 (W) x 480 (H) x 400 (D) 980 (W) x 1725 (H) x 865 (D)
MKT240-400V 228 -70°C to +180 °C 735 (W) x 700 (H) x 443 (D) 1115 (W) x 1935 (H) x 925 (D)
MKT240-480V-C 228 -70°C to +180 °C 735 (W) x 700 (H) x 443 (D) 1115 (W) x 1935 (H) x 925 (D)
MKT720-400V 734 -70°C to +180 °C 1200 (W) x 1020 (H) x 600 (D) 1580 (W) x 2005 (H) x 1140 (D)
MKT720-480V-C 734 -70°C to +180 °C 1200 (W) x 1020 (H) x 600 (D) 1580 (W) x 2005 (H) x 1140 (D)



For a comprehensive overview of the technical data of our MKT Series Dynamic Climate Chambers, please download the “Data Sheet” further up the page.
