Krebs Viscometer

Krebs Viscometer

Manufactured by Rhopoint Instruments

Ensuring consistent quality standards at each stage of the manufacturing process is easy with the Krebs Viscometer

Many parameters can affect the rheological behaviour of a finished coating resulting in undesirable affects such as sagging, levelling, brushability and atomisation. The use of high precision measuring instruments is therefore essential in quality control to prevent such problems occurring during formulation, manufacture and application.

The PAINTLAB+ Krebs Viscometer from Rhopoint Instruments offers high accuracy viscosity measurement with advanced functionality.

Krebs Viscometer Features:

  • Real time high resolution graphing of test samples
  • Results displayed on screen immediately after test in KU, g and cP
  • High stability motor speed control for accuracy and repeatability of measurement
  • Integrated temperature probe to check and record sample temperature prior to testing
  • Automatic lowering of paddle to test height for selected container
  • Quick release magnetic paddle for easy removal and cleaning
  • Easy clean design- even in the harshest environment both screen and chassis are easy to clean
  • Date / time stamped results output to printer
  • Annual re-calibration can be performed by user
  • Extended warranty

We now offer onsite & offsite viscometer calibration services. Get in touch if you’d like to know more.

All specifications, illustrations and descriptions of products are intended to give a general idea of the products available and are subject to alteration. We reserve the right to substitute an alternative of similar specification at our discretion. We have taken all reasonable steps to ensure the accuracy of product information provided, but we accept no liability for any errors or omissions.


ASTM D562 Standard Test Method for Consistency of Paints Measuring Krebs Unit (KU) Viscosity Using a Stormer-Type Viscometer

Technical Specification

Resolution: 0.1 KU / 1 g
Accuracy: +/- 1%
Reproducibility: 0.5%
Range: 40 to 141 KU 32 to 1,099 g 27 to 5,274 cP

Speed: 200 rpm +/- 0.1 rpm
Container sizes: 250 ml, 500 ml, 0.5 pint, 1 pint
Operating temperature: 10°C to 40°C
Power: 110/230V
Weight: 7.25kg
Size: (H) 460 x (W) 320 x (D) 190 mm
Packed weight: 10kg
