Benefits
- Precise control of heat sealing process variables (temperature, pressure, and time), enables an optimal balance of material specification, packaging machine speed, and seal integrity.
- Precise pressure calibration of standard surface area jaw face.
- Jaws constructed in aluminium and silicon with precision ground faces.
- Range of jaw face surfaces including Matched Crimp and Teflon Coating.
- Auto cycle feature for greater user convenience with multiple samples.
- Choose heat sealing bar configuration, either single (upper) or dual (upper & lower, meets ASTM F2029).
- User can easily change sealing bar for various surface areas or surface finishes.
- Accurate and repeatable seals due to precision ground sealing faces and jaw guidance system.
- Low Maintenance — 12 months between calibrations.
Applications
- Versatile applications for flexible materials, blister packs, and pots.
Seal Width: 300 mm max. (Option to extend to 350mm).
Temperature Control:Range: Ambient to 300°C, Accuracy: +/- 0.5%, Operating Accuracy: +/-2°C. Single (Upper) sealing jaw temperature control, or Dual (Upper & Lower) sealing jaw temperature control.
Pressure: Range: 0 to 100psi (6.8bar, 689Kpa), via precision regulator and digital display. Accuracy +/-5%, Repeatability +/- 0.02psi .
Supply via clean and dry compressed airline or bottled air/nitrogen at 90 to 100psi.
Dwell Time: Range: 0.1 to 99.9 sec., Resolution 0.01 sec.
Auto Cycle & Delay Time: Delay Time Range: 0.1 to 99.9 sec For automatic cycling of sealing bars used in manual production environments. Assists with correct alignment of sample. Electronic processor controlled.
Jaw Guidance System:Dovetail slide on jaws with quick release mechanism.
Sealing Jaws: Standard flat jaws 25mm x 300mm, constructed in aluminium with precision ground face. Lower sealing jaw with precision ground silicone rubber face.
Environment: 5-50°C ambient operating temperature, RH 75% max (non-condensing).
Power: 240V AC 50/60 Hz (110V AC voltage available on request).
Dimensions: W 50 x D 41 x H 49cm, 28kg.
Accessories
- Single (Upper) sealing jaw temperature control or Dual (Upper & Lower) sealing jaw temperature control.
- Sealing jaw dimension/profile as required (inc. Matched crimp 120° x 1.8mm pitch).
- Stainless Steel sealing jaws.
- Teflon Coated Tape or Teflon Coated Jaws.
- Blister Pack Simulator sealing jaw.
- Additional Blister tray.
- Footswitch.
- PVC Dust Cover.
- Alarm package for temperature High/Low, selectable.
- Cold seal system.
- Digital thermometer with s/s band probe to check jaw temperature.
