Eccentric Roller Grip

Eccentric Roller Grip for Tensile and Materials Testing

Our Eccentric Roller Grips can be supplied to fit all brands of machine, let us know which machine and we shall ensure it fits!

Below is a small selection of the grips which we offer, these are all manufactured in Germany to the highest quality standards, Please see the attached data sheet for more pictures and information, which are part of an even larger collection. Please contact us with the type of testing you wish to use the Eccentric Roller Grip for and our friendly engineers will gladly advise on the best ones for your application.

AML also supply a huge range of other Tensile Tester grips and fixtures

Easy to use and self-tightening

Applicable for soft and flexible samples, foils, plastics, rubber etc.

Eccentric Roller Grip TH7-1

Pyramid (serrated) faced roller, 25mm Ø
Clamping width 50mm, specimen thickness 0– 7 mm
Tensile force: 1 kN
Temperature range: 0 – 130°C
Other temperature ranges possible on request
509 gram aluminium anodized

Eccentric Roller Grip TH7-1-SR

Smooth roller, 25mm Ø, rubber base plate
Clamping width 50mm,specimen thickness 0 – 7mm
Tensile force: 1 kN
Temperature range: 0– 70°C
Other temperature ranges possible on request
509 gram aluminium anodized

Eccentric Roller Grip TH7-5

Tensile force: 5kN
Clamping width 50mm,specimen thickness 0 – 7mm
Pyramid (serrated) faced roller, 30mm Ø
Temperature range: 0– 130°C
Other temperature ranges possible on request
Body: aluminium anodized
Weight: 667 gram each grip

Eccentric Roller Grip TH7-10

Tensile force 10kN
Pyramid (serrated) faced roller, 50mm Ø
Clamping width 60mm,specimen thickness 0 – 8mm
Temperature range: 0 – 130°C
Other temperature ranges possible
Body: steel, manganese phosphate coating
Weight :3,35kg each grip

Eccentric Roller Grip TH7-20

Tensile force: 20 kN
Pyramid (serrated) faced roller, 50 mm Ø, steel, nickel-plated
Clamping width 60 mm, specimen thickness 0 – 8 mm
Body: steel, nickel-plated
Temperature range: 0 … +130°C- Other temperature ranges on request
Weight: ca. 3.52 kg each grip
