Benefits
- Clever alternative to complex individual solutions for cyclical temperature tests.
- line™ preheating chamber technology.
- Programmable condensation protection for test material.
- Heated viewing window with LED interior lighting enables you to easily inside the chamber.
- BINDER Multi Management Software APT-COM™ Basic Edition.
- Troubleshooting system with visual and audible alarms.
- Intuitive touchscreen controller with time-segment and real-time programming.
- Internal data logger, measured values can be read out in open format via USB.
- Access port with silicone plug, 50 mm, left.
- Class 2 independent adjustable temperature safety device (DIN 12880) with visual alarm.
- Four castors, two with brakes for easy manoeuvrability.
- Computer interface: Ethernet.
- V power socket on the right-side control panel.
- Adjustable ramp function.
- Integrated chart recorder.
- Real-time clock.
- Door heating.
- One stainless steel rack.
- Durable stainless steel inner chamber.
- CFC-free refrigerant R-452A.
- Cooling with compressor cooling unit.
- Environmental chamber calibration service available.
Safety packages tailored to your test requirements
BINDER offers test chambers for aging, performance, and stress tests. Their A | P | P Plus | S safety packages are designed specifically for tests conducted on lithium-ion batteries.
Depending on the application, they can equip your thermal chambers with extended safety features. Please contact us to let us know your requirements.
| Model | Interior Volume (L) | Temperature Range | Internal Dimensions (mm) | Housing Dimensions (mm) (Not including fittings and connections) |
| MK056-230V | 60 | -40°C to +180°C | 400 (W) x 420 (H) x 350 (D) | 720 (W) x 1445 (H) x 778 (D) |
| MK056-240V | 60 | -40°C to +180°C | 400 (W) x 420 (H) x 350 (D) | 720 (W) x 1445 (H) x 778 (D) |
| MK115-400V | 115 | -40°C to +180°C | 600 (W) x 480 (H) x 400 (D) | 980 (W) x 1725 (H) x 865 (D) |
| MK115-480V-C | 115 | -40°C to +180°C | 600 (W) x 480 (H) x 400 (D) | 980 (W) x 1725 (H) x 865 (D) |
| MK240-400V | 228 | -40°C to +180°C | 735 (W) x 700 (H) x 443 (D) | 1115 (W) x 1710 (H) x 925 (D) |
| MK240-480V-C | 228 | -40°C to +180°C | 735 (W) x 700 (H) x 443 (D) | 1115 (W) x 1710 (H) x 925 (D) |
| MK400-400V | 417 | -40°C to +180°C | 735 (W) x 700 (H) x 810 (D) | 1115 (W) x 1710 (H) x 1400 (D) |
| MK400-480V-C | 417 | -40°C to +180°C | 735 (W) x 700 (H) x 810 (D) | 1115 (W) x 1710 (H) x 1400 (D) |
| MK720-400V | 734 | -40°C to +180°C | 1200 (W) x 1020 (H) 600 (D) | 1580 (W) x 2005 (H) x 1140 (D) |
| MK720-480V-C | 734 | -40°C to +180°C | 1200 (W) x 1020 (H) 600 (D) | 1580 (W) x 2005 (H) x 1140 (D) |
| MK1020-400V | 991 | -40°C to +180°C | 1200 (W) x 1020 (H) x 810 (D) | 1580 (W) x 2005 (H) x 1480 (D) |
| MK1020-480V-C | 991 | -40°C to +180°C | 1200 (W) x 1020 (H) x 810 (D) | 1580 (W) x 2005 (H) x 1480 (D) |
For a comprehensive overview of the technical data of our MK Series BINDER Dynamic Climate Chambers, please download the “Data Sheet” further up the page.
