400 to 2000kN Servo Hydraulic Universal Testing Machines DI-CP-V4 HOYTOM® PRO Series

400 to 2000kN Servo Hydraulic Universal Testing Machines DI-CP-V4 HOYTOM® PRO Series

Manufactured by Hoytom

Servo Hydraulic Universal  Testing  Machines DI-CP-V4 HOYTOM® PRO Series

The DI-CP-V4 is part of the Hoytom Pro Series of Servo Hydraulic Universal Testing Machines from Hoytom in Spain.

In a range of capacities from 400 to 2000kN.

Dual testing area, tensile in the lower area and comes equipped with hydraulic wedge grips. The upper area is used for bend and compresive tests.

Hoytom HoyWin® powerful yet initiative software & PC supplied with every machine.

These servo hydraulic testing machines are highly capable of performing tests on any material regardless of how hard or tough it might be.

  • Tensile – Compression – Bending – Shear… tests3 Year Warranty on servo hydraulic testing machines
  • HBM® loadcell (World leader in load cells)
  • Servo-hydraulic Close Loop Control
  • 3 year warranty
  • Manufactured in Spain by Hoytom
  • Force capacity :  400 to 2000 kN capacity models
  • Loadcell Accuracy : +/- 0,5 % (EN ISO 7500 Class 0.5 ASTM E4)
  • Loadcell range 0.4% – 100%

Servo Hydraulic Universal  Testing  Machines, standard delivery includes :

  • Load Cell Tension/Compression of (400 – 600 – 1000 – 1500 – 2000 kN according model)HBM Loadcell
  • HYDRAULIC Tensile Grips & 1 set of jaws
  • ENAC Calibration Certificate (equivalent to UKAS)
  • PC with Hoytom HoyWin® software pre-installed.
  • Installation, training & support by AML Instruments’s UK based engineers.

Optional extras

  • Extensometers from Epsilon & MF
  • Grips, jaws and fixtures for just about any test to any National or International standard
  • Safety guards with interlock.

Is this not the Universal Testing Machine / Tensile Tester you were looking for? We have a huge range of Materials Testing Machines Available

Capacity kN 400 – 600 1000 1500 – 2000
Piston speed*1mm Forward
Backward
150
200
150
200
100
150
Piston travel mm 500
Separation between grips mm 100 – 600
Tensile horizontal space mm 620 750 810
Compressive horizontal spacemm 340 440 500
Maximum height mm 3400 3900 4000
Dimensions mm Width
Depth
Height
1050
900
2900
1250
1000
3400
1250
1000
3500
Weight Kg 3600 5000 6000
Power supply V 380 – III
Force transducer
Machine accuracy (Class)*2 0.5
Range 0.4% – 100% FS
Resolution 0.001% FS



Displacement transducer
Type Encode line
Resolution < 0.01 mm
Precision < 0.1%
  • *1 Higher speeds and dimensions available upon request.
  • *2 According to Standards ISO 7500 and ASTM E4.
