Benefits
- Total control over your coating thickness measurements, avoiding the need for frustrating and costly rework and rejects.
- Portable and durable, offering contactless and non-destructive support in industrial environments, with zero dangerous emissions.
- Expect fast and reproducible measurements, even on critical parts with narrow or moving surfaces.
- Contactless, non-destructive control over the testing of your coatings.
- Follows the thermal layer testing (TLT) principle, with the patented technology not relying on magnetic induction or ultrasound.
- Saves coating material and protects the environment.
- Brings the coating process for coils into the target range after only a few metres.
- Savings of coil and coating material pay for themselves in just a few months.
- Large tilt intolerance of 70° (depending on coating and substrate material).
- Suitable for thicker layer thicknesses.
- Suitable for measuring moving parts.
- Suitable for dry and wet film coatings.
- Measurement data securely stored in the cloud.
- Comes supplied with a rechargeable battery 18V (2x) and charger; and a durable transport case.
Suitable Applications & Materials
Applications: Coating testing, thickness testing.
Materials: Paints and coatings.
Cured powder / dried paints: 1 – 1000 μm.
Wet paints before drying: 1 – 400 μm.
Powder coatings before curing: 1 – 400 μm.
Measuring time: From 20 ms.
Distance tolerance: 2 – 15 cm (Depending on coating and substrate material).
Tilt tolerance: 1 ± 70°.
Measurement on moving parts: Yes.
Relative standard deviation: 1 % (60 μm powder coating before curing on aluminum, 5 cm working distance).
Measures coatings of any color (incl. white): Yes.
Real-time data access via ERP and browser: Yes.
Weight (without battery): 1.3 kg.
Dimensions: 374 x 91 x 203 mm.
Important: All information applies to a typical coating system and substrate. The exact limits always depend on the physical properties of the coating material.
