Rapid Temperature & Humidity Chambers Series MKF

Rapid Temperature & Humidity Chambers Series MKF

Manufactured by BINDER

Designed for industrial material testing and environment simulation applications, the MKF Series Dynamic Climate Chamber is suited for any cold and heat testing based on current temperature and climate testing methods according to DIN and IEC standards.

Ideal for rapid temperature changes with humidity control, these climatic chambers enable easy data management and programming via a vibrant colour display.

It’s available in six different sizes with interior volumes ranging from 60 litres to 991 litres. All models have a temperature range of -40°C to +180°C, a humidity range of 10% to 98% RH, and come with a voltage choice of 230V or 240V.





Benefits

  • Higher capacity which exceeds the capability of normal testing chambers.
  • Comprehensive standard equipment for this environmental simulation chamber ensures ease of operation.
  • 4 zero-voltage relay contacts that can be activated via MCS controller.
  • APT.line™ preheating chamber technology ensures homogeneous climate conditions.
  • Automatic water and wastewater management.
  • Pressure humidification with fast response times.
  • Programmable condensation protection for test material.
  • Heated viewing window with LED interior lighting allows you to easily see what’s going on inside the chamber.
  • Humidity regulation with capacitative humidity sensor and vapour humidification.
  • BINDER Multi Management Software APT-COM™ Basic Edition.
  • Troubleshooting system with visual and audible alarms.
  • Intuitive touchscreen controller with time-segment and real-time programming.
  • Internal data logger, measured values can be read out in open format via USB.
  • Unit self-test for comprehensive status analysis (only applicable to model MKF 56).
  • Access port with silicone plug: 50 mm, left.
  • Four castors, two with brakes to easily move the chamber from A to B.
  • Computer interface: Ethernet.
  • Adjustable ramp function.
  • Integrated chart recorder.
  • Real-time clock.
  • Door heating.
  • Stainless steel rack.
  • Inner chamber made of hygienic and robust stainless steel.
  • Complete safety connection kit for water supply and drainage, up to 1 m height.
  • CFC-free refrigerant R-452A.
  • Cooling with compressor cooling unit
  • Unit self-test for comprehensive status analysis (only applicable to model MKF 56).
  • Fin evaporator (only applicable to model MKF 56).
  • Thermal insulation using PUR foam (only applicable to model MKF 56).
  • Integrated 20 litre water storage tank (not applicable to model MKF 56).
  • Alarm notification in the event of insufficient water in fresh water tank (not applicable to model MKF 56).
  • Temperature and humidity calibration service available.
Model Interior Volume (L) Temperature Range Humidity Range Internal Dimensions (mm) Housing Dimensions (mm) (Not including fittings and connections)
MKF 56 60 -40°C to +180°C 10% to 98% RH 400 (W) x 420 (H) x 348 (D) 720 (W) x 1445 (H) x 780 (D)
MKF 115 115 -40°C to +180°C 10% to 98% RH 600 (W) x 480 (H) x 400 (D) 980 (W) x 1725 (H) x 865 (D)
MKF 240 228 -40°C to +180°C 10% to 98% RH 735 (W) x 700 (H) x 443 (D) 1115 (W) x 1715 (H) x 925 (D)
MKF 400 417 -40°C to +180°C 10% to 98% RH 735 (W) x 700 (H) x 810 (D) 1115 (W) x 1710 (H) x 1400 (D)
MKF 720 734 -40°C to +180°C 10% to 98% RH 1200 (W) x 1020 (H) x 600 (D) 1580 (W) x 2005 (H) x 1140 (D)
MKF 1020 991 -40°C to +180°C 10% to 98% RH 1200 (W) x 1020 (W) x 810 (D) 1580 (W) x 2005 (W) x 1480 (D)



For a comprehensive overview of the technical data of our MKF Series Dynamic Climate Chambers, please download the “Data Sheet” further up the page.
