Illuminated Colour Assessment Cabinet (LED)

Benefits

• Select from a range of light sources that assess everything from gloss and metamerism through to structure and damages.
• Easy on the eye — both the interior and the exterior are finished to the highest quality and colour assessment standards.
• Made of robust MDF material, painted on the inside in neutral matt Munsell N5,5 Grey.
• Microprocessor controlled, allowing you to switch between different paint inspection light sources instantly without any flickering.
• Several paint inspection light sources may be activated at the same time.
• Correctly records the usage time of each lamp group, so you know when it’s time to change the lamps, ensuring the most accurate results.
• Comes with a UV paint inspection light source to examine samples containing fluorescent optical brighteners or whitening dyes.
• Features D65 and D50000 daylight paint inspection light sources that conform to international testing standards including ISO 3668.
• For simulating indoor light conditions, the cabinets offer incandescent light sources, as well as “shop light” TL84.
• Built to certified paint inspection light testing standards, including ISO 3664, ISO 3668, and ASTM D172.
• Removable viewing table in Munsell N5,5 Grey and individual light tube runtime counters included.

How to use the illuminated colour assessment cabinet

Simply plug in, switch on and press the D65 lamp button to light it up. You can use more than one paint inspection light source at the same time — just select the appropriate buttons.

Next up, place your samples at the centre of the colour assessment cabinet. If you’re using the paint inspection light(s) to check two or more samples at once then it’s best to place each in parallel and avoid overlapping them before observing.

When you’re finished, simply switch off the colourbox using the one/off key.

Our colour assessment cabinet timers show you the total service time of the cabinet. While the total operating time of each individual light source (F, TL84 or UV) is displayed and recorded.

Suitable Applications & Materials

Applications: Coating testing.

Materials: Inks and coatings, paper, plastics and polymers, textiles.
